Big-job portable power with a proven Vanguard V-Twin. The WL19000VE-03/A combines WINCO’s industrial alternator with a Briggs & Stratton Vanguard 993cc engine, giving you 120/240V single-phase output and a receptacle set built for real loads. It’s a favorite for rigs, construction, and facility backup where reliability matters. (This is the direct replacement for the discontinued WL18000VE.)
Add These Essentials to Your WL22000VE-03/A
Bundle the cord parts and service items you need for your transfer/inlet setup.
Key Features
- Vanguard® 993cc: Commercial V-Twin with full-pressure lubrication and spin-on oil filter.
- Industrial Alternator: Built for tough duty with stable output for tools and equipment.
- YourGen-style metering: Hour/voltage/frequency visibility to manage loads and service.
- Powder-Coated Cradle: 14-gauge welded tubular steel for durability.
- 15-Gallon Tank: Extended runtime with gauge.
- Premium breakers & 100% load-tested at the factory.
Outputs & Receptacles (03/A Panel)
- Voltage: 120/240V single phase
- 120V: (2) NEMA 5-20R GFCI duplex
- 120/240V: (1) NEMA 14-60 60A; (1) NEMA L14-30 30A GFCI
- 240V: (1) NEMA L6-30R 30A GFCI
Receptacle set per Winco’s WL19000VE product page for the 03/A configuration.
Performance & Specs
| Starting Watts | 19,000 |
| Running Watts | 17,000 |
| Running Amps | 79.1 @ 240V / 70.8 @ 277V* |
| Voltage Output | 120/240V, single phase |
| Voltage Regulation | Capacitor |
| Engine Brand | Briggs & Stratton Vanguard (993cc) |
| Fuel | Gasoline |
| Emissions | EPA Prime |
| Dimensions (Unit) | 43″ x 28.85″ x 28.85″ |
| Weight | ~504 lbs |
| Warranty | 3 Years Commercial |
| Assembled In | USA |
*Amps shown per dealer spec tables; use 120/240V loads only.
Downloadable PDF’s
WL19000VE- General Spec-Sheet (PDF)
WL19000VE- General Operators Manual (PDF)
WL19000VE- General Load Balancing Manual (PDF)
WL19000VE- General Tri-Fold Brochure (PDF)
WL19000VE- Vanguard Engine Operators Manual (PDF)
WL19000VE- Vanguard Engine Parts List (PDF)
L19000VE- Vanguard Engine EPA Certificate (PDF)
WL19000VE- Battery Spec-Sheet (PDF)
WL19000VE- Dolly Kit Installation Instructions (PDF)
Ideal Uses
-
Spray rigs & mobile shops needing sustained 120/240V power
-
Construction/agriculture with high inrush loads (compressors, welders, pumps)
-
Temporary facility backup via manual transfer switch
FAQs
Does the WL19000VE-03/A have a full-power Anderson connector?
No. The 03/A panel provides a 60A (14-60) + 30A (L14-30 GFCI) plus 120V GFCI duplexes and a 240V L6-30 GFCI. For an Anderson full-power connector, see WL22000VE-03/C.
What maintenance kit and battery fit?
Maintenance kit 16200-011 (Vanguard 35 HP) and 12V Group 26 battery 80765-013. (Cross-sell items you already list.)
Is there a dolly kit?
Yes—use 16199-040 for WL-series mobility
