Graco Reactor 2 E-30 Electric Proportioner – Part #EHR312
Product Overview
The Graco Reactor 2 E-30 is an electric spray foam proportioner designed for dependable performance in mid- to high-volume applications. With a powerful 30 lb/min output rate and precision 1:1 mix control, it is built to tackle commercial insulation, residential retrofits, and polyurea coating jobs.
Equipped with a 10.2 kW heating capacity and real-time temperature monitoring, the E-30 ensures stable material performance even during extended spray sessions. Its durable design, 2000 psi pressure rating, and intuitive LED controls make it a contractor favorite for consistent results.
From foam insulation to demanding polyurea jobs, the Reactor 2 E-30 balances output, control, and reliability—helping professionals stay productive, job after job.
Key Features
Output & Material Flow
- 30 lb/min (13.6 kg/min) output for rapid project coverage
- Fixed 1:1 mix ratio ensures accurate chemical blending
- Compatible with polyurethane foams and polyurea coatings
Heating & Pressure Control
- Integrated 10.2 kW heating capacity maintains stable material temps
- Supports up to 2000 psi (13.8 MPa) fluid pressure
- Optimized for hose lengths up to 310 ft (94.5 m)
Digital Interface & Diagnostics
- LED display provides critical spray metrics and system status
- Built-in troubleshooting features minimize downtime
- Simple interface streamlines daily operation and calibration
Serviceability
- Modular components improve access and reduce repair time
- Rugged steel frame resists wear in jobsite environments
- Electronics and pumps designed for field reliability
Product Specifications
| Specification | Details |
|---|---|
| Product Type | Proportioner |
| Compatible Materials | Spray Polyurethane Foam (SPF), Polyurea |
| Max Fluid Pressure | 2000 psi (13.8 MPa) |
| Max Hose Length | 310 ft (94.5 m) |
| Output Rate | 30 lb/min (13.6 kg/min) |
| Heating Capacity | 10.2 kW |
| Power Supply | 200–240 VAC, 1- or 3-Phase |
| Control Interface | LED Panel |
| Reactor Series | Reactor 2 E-30 |
| Mix Ratio | 1:1 Fixed |
