10pk of Stingers for Handi-Gun II

One end will have a clean, flush cut; the other end will have a beveled end that comes to a point.

The clean cut end will insert into the push-lock fitting on the air line cutoff valve. The beveled end will insert through the top of the gun until it comes out of the top hole on the face of the gun. Push/Pull the beveled end past the gun face about 1/2″ so that you can cut off the beveled point and leave a clean, uniform hole through the air line that sits flush with the face of the gun. If the air line sticks out too far from the gun face, this can prevent the mix chamber from fully seating. Simply cut off the excess, or pull back from the top of the gun until the air line sits flush with the gun face and allows the mix chamber to be fully seated/flush with the gun face.

*You may have to use the pliers from the Handi-Gun II Maintenance Kit (221542) to pull the beveled end through the gun face as it should be a tight fit.
