IP-01
IPM’s IP-01 series of pumps are general purpose transfer pumps designed for use with a wide variety of materials. The air driven motor is designed with simplicity in mind for years of use in less than desirable conditions.
Features

Fully air operated.
2 ball piston design provides uniform positive displacement.
Extremely durable pump with long life packing.

IP-02

IPM’s IP-02 series of pumps are specifically designed for use with difficult to handle materials. The immersed lower pump, tie tubes, and sealing bung bushing allow quick drum change without exposing the system to contamination and moisture

Features

Fully air operated
2 ball piston design provides uniform positive displacement
Extremely durable pump with long life packing
Specially designed piston seals do not come into contact with material pumped. Hence, very long life as it can handle highly problematic fluids like Isocyanates which crystallizes on piston rods upon contact with moisture in air and rupture seals.

OP Series


Air Operated Fluid Pump

Features

Fully air operated.
2 ball piston design provides uniform positive displacement.
Extremely durable pump with long life packing.
Specially designed piston seals do not come into contact with material pumped. Hence, very long life as it can handle highly problematic fluids like Isocyanates which crystallizes on piston rods upon contact with moisture in air and rupture seals.

DM-101

The DM-101 Drum Mixer is a very effective tool in mixing 55 gallon drums. Complete mixing can be achieved in short periods of time, usually within 30 minutes. The unique design of the blade allows the mixing blade to pass through the 2″ NPT opening in the drum. With two 6″ and one 8″ blade, optimum mixing is achieved throughout the drum.

Features

Fully air operated
No problem with stalling. Will not burn out as associated with electrical motors
High powered with 1/4 HP air motor
Speed can be easily adjusted by turning the air inlet needle valve
Can be easily inserted into the drum through any 2 inch diameter hole when blades are collapsed
Collapsible blades swing out by centrifugal force when it rotates
Highly efficient axial flow impellar
Very effective for all kinds of fluids which require agitation
Quantity and position of blades can be varied to suit your requirements
Wetted parts are made of stainless steel
